RS Virla Group

TMT Bar

Physical Properties

GRADE FE-500 FE-550 FE-600 FE-700
YIELD STRESS
(N/mm²) Min		 500D 550D 600 700
Tensile Strength
(N/mm²) Min Ratio		 >1.10 More Than Actual 2.0% Proof Stress/Yield Stress But not less than 565 N/mm² 1.08 More Than Actual 2.0% Proof Stress/Yield Stress But not less than 600 N/mm >1.06 More Than Actual 2.0% Proof Stress/Yield Stress But not less than 660 N/mm >1.04 More Than Actual 2.0% Proof Stress/Yield Stress But not less than 760 N/mm

CHEMICAL PROPERTIES

GRADE FE-500D FE-500D FE-550D FE-550D FE-600D EQR600 FE-700 FE-700
(%) Max BIS:1786 RS VIRLA BIS:1786 RS VIRLA BIS:1786 RS VIRLA BIS:1786 RS VIRLA
CARBON 0.25 0.18-0.25 0.25 0.18-0.23 0.30 0.18-0.25 0.30 0.18-0.25
SULPHUR 0.040 0.030-0.035 0.040 0.025-0.035 0.040 0.025-0.035 0.040 0.025-0.035
PHOSPHORUS 0.040 0.028-0.035 0.040 0.025-0.035 0.040 0.025-0.035 0.040 0.025-0.035
S+P 0.075 0.062-0.070 0.075 0.062-0.070 0.075 0.062-0.070 0.075 0.062-0.070

PRODUCT RANGE

NOMINAL SIZE (mm) BIS STANDARDS WEIGHT PER METER IN KG RS VIRLA EQR600 PER METER IN KG BIS TOLERANCE RS VIRLA EQR600 BIS TOLERANCE
8 0.395 0.397-0.390 +7% +4%
10 0.615 0.592-0.600 +7% +4%
12 0.888 0.861-0.880 +5% +3%
16 1.532-1.560 0.861-0.880 +5% +3%
20 2.470 2.420-2.450 +3% +2%
25 3.850 3.773-3.840 +3% +2%
28 4.830 4.735-4.800 +3% +2%
32 6.310 6.184-6.300 +3% +2%
36 7.990 7.800-7.900 +3% +2%
40 9.860 9.663-9.860 +3% +2%
